Plan No. 5006
5 Bedroom | 4.5 Bath | 5,006 SF Home
Additional Features:
Plan Description
5 Bedroom | 4.5 Bath | 5,006 SF Home
This magnificent rustic lodge style masterpiece offers an extraordinary 5,006 square feet of grand, character-rich living space featuring 5 bedrooms, 4.5 bathrooms, and a 3-car garage — designed for those who believe bigger is better and every detail deserves attention. From the moment you step inside, the warmth and craftsmanship of lodge-inspired design surrounds you at every turn. A dedicated office, bonus room, and game room provide endless flexibility for work, relaxation, and entertainment, while a beautiful sunroom floods the home with natural light and brings the outdoors in year-round. The walk-in pantry and mudroom keep daily life organized and running smoothly, and a thoughtfully designed dog room ensures even your four-legged family members have a space to call their own. A built-in safe room adds an important layer of security and peace of mind, making this exceptional lodge-inspired retreat as safe as it is stunning.
$5,250.00
What you will recieve:
Within 1 -2 business days of purchasing your plan, you will be sent an digital Construction Drawing set.
This set includes:
- Exterior Rendering
- Foundation + Plumbing Layout Plan
- Dimensioned Floor Plan
- Exterior Elevations
- Roof Plan
- Door + Window Schedule
- Lighting and Power Plan
- Cross Section + Typical Details
- Site Plan (If add-on is selected)
- Cabinet Elevations (If add-on is selected)
The set does not include:
- Architectural or Engineering Stamp - handled locally if required
- Structural Foundation or Framing Plans
- Mechanical Drawings (location of heating and air equipment and duct work) - your subcontractors handle this
- Plumbing Drawings showing the actual plumbing pipe sizes and locations- your subcontractors handle this
- Energy calculations
CONSTRUCTION DRAWING SET INCLUDES:
Shows boundaries of the foundation and dimensions of plumbing fixtures located in the foundation. This is not a structurally engineered foundation plan, but can be used by an engineer to create one.
Floor plan showing dimensions and annotations for all interior and exterior walls, door and windows, and key elements.
2D view of the homes exterior showing the design, finish materials, critical height relationships, door and window placements, and roof lines.
Top-down view of the roof, including ridge, valley, and hip locations, roof pitches, overhangs, and gutter and downspout locations.
Shows quantity, type, and size of the doors and windows located in the house.
Shows the location of light fixtures, switches, and outlets in the home.
